| E-Z Drive |
|
|
|
|
|
| E-Z Drive Elite |
|
|
|
|
|
| E-Z Drive Premier |
|
|
|
|
|
| Air Connection |
Remote air connection |
Remote air connection |
Remote air connection |
Remote air connection |
Remote air connection |
| Air Leveling |
|
|
|
Valid Truline air leveling system with auxiliary air compressor |
Valid Truline air leveling system with auxiliary air compressor |
| Alternator |
170-amp alternator |
170-amp alternator |
170-amp alternator |
170-amp alternator |
210-amp alternator |
| Braking System |
ABS disc brakes on front axle, drum brakes on drive and tag axle |
ABS disc brakes on front axle, drum brakes on drive and tag axle |
ABS disc brakes on front axle, drum brakes on drive and tag axle |
ABS disc brakes on front axle, drum brakes on drive and tag axle |
All-wheel ABS disc brakes |
| Chassis |
Spartan® K1 raised-rail chassis |
Spartan® K2 raised-rail chassis |
Spartan® K2 raised-rail chassis |
Spartan® K2 raised-rail chassis |
Spartan® K3 raised-rail chassis |
| Chassis Battery |
(2) 12V chassis batteries |
(2) 12V chassis batteries |
(2) 12V chassis batteries |
(2) 12V chassis batteries |
(2) 12V chassis batteries |
| DEF Tank |
10-gal. DEF tank |
10-gal. DEF tank |
15-gal. DEF tank with dual fills (single fill on 40P, 44R) |
15-gal. DEF tank with dual fills (single fill on 44R) |
15-gal. DEF tank with dual fills (single fill on 45R) |
| Engine |
Cummins® B6.7 turbocharged 360-HP engine with 800-lb. ft. torque at 1,800 RPM |
Cummins® L9 turbocharged 380 HP engine with 1,150-lb. ft. torque at 1,400 RPM |
Cummins® L9 turbocharged 450 HP engine with 1,250-lb. ft. torque at 1,400 RPM |
Cummins® L9 turbocharged 450 HP engine with 1,250-lb. ft. torque at 1,400 RPM |
Cummins® 15-liter X15 turbocharged 605 HP engine with 1,950-lb. ft. torque at 1,150 RPM |
| Engine Block Heater |
750-watt engine block heater |
1,000-watt engine block heater |
1,000-watt engine block heater |
1,000-watt engine block heater |
1,500-watt engine block heater |
| Engine Brake |
Variable geometry turbo (VGT) engine brake |
Variable geometry turbo (VGT) engine brake |
Two-stage engine brake |
Two-stage engine brake |
Three-stage engine brake |
| Front Axle |
Front axle- 12,600 lb. (37K) 14,320 lb. (39BH/39T2) |
Front axle- 14,320 lb. rating |
Reyco® Granning® front axle - 17,000 lb. rating |
Reyco® Granning® front axle - 20,000 lb. rating |
Reyco® Granning® - 20,000 lb. rating |
| Front Suspension |
Independent front air suspension (IFS) |
Independent front air suspension (IFS) |
Independent front air suspension (IFS) |
Independent front air suspension (IFS) |
Independent front air suspension (IFS) |
| Fuel Tank |
100-gal. fuel tank |
100-gal. fuel tank |
150-gal. fuel tank with dual fills (100 gal. on 40P) |
150-gal. fuel tank with dual fills |
150-gal. fuel tank with dual fills |
| Hitch |
10,000-lb. hitch with 7-pin plug |
10,000-lb. hitch with 7-pin plug |
15,000-lb. hitch with 7-pin plug (10,000-lb. hitch on 40P) |
15,000-lb. hitch with 7-pin plug |
20,000-lb. hitch with 7-pin plug |
| Leveling System |
Equalizer™ hydraulic automatic coach leveling |
Equalizer™ hydraulic automatic coach leveling |
Equalizer™ hydraulic automatic coach leveling |
Equalizer™ hydraulic automatic coach leveling |
Equalizer™ hydraulic automatic coach leveling |
| Radiator |
Rear-mounted radiator |
Rear-mounted radiator |
Side-mounted, parallel-airflow radiator |
Side-mounted, parallel-airflow radiator |
Side-mounted, parallel-airflow radiator |
| Rear Axle |
Rear axle - 20,000 lb. (37K) 22,000 lb (39BH/39T2) |
Rear axle - 22,000 lb. rating |
Meritor rear axle - 20,000 lb. rating (Dana® rear axle- 24,000 lb. rating on 40P) |
Meritor rear axle - 20,000 lb. rating |
Dana® rear axle - 20,000 lb. rating |
| Rear Axle Ratio |
4.88 rear axle ratio |
4.88 rear axle ratio |
4.88 rear axle ratio (4.78 on 40P) |
4.88 rear axle ratio |
4.30 rear axle ratio |
| Rear Suspension |
|
|
|
|
|
| Ride & Handling Package |
|
|
|
|
|
| Shocks |
Bilstein® 46mm shocks |
Bilstein® 46mm shocks |
Bilstein® 46mm shocks |
Bilstein® shocks- 60mm front axle & 46mm rear/tag axles |
Bilstein® shocks- 60mm front axle & 46mm rear/tag axles |
| Tag Axle |
|
|
Tag axle with air dump - 12,000 lb. rating (N/A 40P) |
Tag axle with air dump - 12,000 lb. rating |
Reyco® Granning® passive-steer tag axle with air dump - 14,000 lb. rating |
| Tires |
Michelin® 275/80R 22.5” tires |
Michelin® 275/80R 22.5” tires |
Michelin® 315/80R 22.5” tires (front) and 295/80R 22.5” tires (rear) |
Michelin® XZA 365/70R 22.5” tires (front) and XZA 315/80R 22.5” tires (rear) |
Michelin® 365/70R 22.5” tires (front) and 315/80R 22.5” tires (rear) |
| Tire Pressure Monitoring |
Tire pressure monitoring system (TPMS) with temperature monitoring |
Tire pressure monitoring system (TPMS) with temperature monitoring |
Tire pressure monitoring system (TPMS) with temperature monitoring |
Tire pressure monitoring system (TPMS) with temperature monitoring |
Tire pressure monitoring system (TPMS) with temperature monitoring |
| Tow Air Brake System |
Spartan® Safehaul tow vehicle air brake system |
Spartan® Safehaul tow vehicle air brake system |
Spartan® Safehaul tow vehicle air brake system |
Spartan® Safehaul tow vehicle air brake system |
Spartan® Safehaul tow vehicle air brake system |
| Traction Control |
|
|
|
Automatic traction control |
Automatic traction control |
| Transmission |
Allison® 3,000 MH 6-speed transmission |
Allison® 3,000 MH 6-speed transmission |
Allison® 3,000 MH 6-speed transmission |
Allison® 3,000 MH 6-speed transmission |
Allison® 4,000 MH 6-speed transmission |
| Turning Radius |
|
|
|
|
|
| Exterior Walls |
|
|
|
|
|
| Floor |
Vacuum-bonded layers of Darco underbelly, a welded aluminum frame, R-9 bead-foam insulation, 3/8" Structurwood® and 1/4" plywood |
Vacuum-bonded layers of Darco underbelly, a welded aluminum frame, R-9 bead-foam insulation, 3/8" Structurwood® and 1/4" plywood |
2" x 4" wood trusses on 16" centers or less filled with bat and Flexfoil insulation then topped with 3/4" 7-ply plywood decking (R-33) |
2" x 4" wood trusses on 16" centers or less filled with bat and Flexfoil insulation then topped with 3/4" 7-ply plywood decking (R-33) |
2" x 4" wood trusses on 16" centers or less filled with bat and Flexfoil insulation then topped with 3/4" 7-ply plywood decking (R-33) |
| Floor Decking |
|
|
|
|
|
| Frame |
X-Bridge™ bracing welded into chassis frame |
X-Bridge™ bracing welded into chassis frame |
X-Bridge™ bracing welded into chassis frame |
X-Bridge™ bracing welded into chassis frame |
X-Bridge™ bracing welded into chassis frame |
| Front Cap |
Insulated front and rear caps (R-24) with steel-reinforced front cap and windshield frame |
Insulated front and rear caps (R-24) with steel-reinforced front cap and windshield frame |
Insulated front and rear caps (R-24) with steel-reinforced front cap and windshield frame |
Insulated front and rear caps (R-24) with steel-reinforced front cap and windshield frame |
Insulated front and rear caps (R-24) with steel-reinforced front cap and windshield frame |
| Insulation |
|
|
|
|
|
| Roof |
One-piece fiberglass with 3/8" plywood decking, 4" arched aluminum trusses, insulation and reflective Flexfoil® (R-24) |
One-piece fiberglass with 3/8" plywood decking, 4" arched aluminum trusses, insulation and reflective Flexfoil® (R-24) |
4" arched aluminum trusses filled with bat insulation and reflective Flexfoil® topped with 3/8" plywood decking then one-piece fiberglass |
4" arched aluminum trusses filled with bat insulation and reflective Flexfoil® topped with 3/8" plywood decking then one-piece fiberglass |
4" arched aluminum trusses filled with bat insulation and reflective Flexfoil® topped with 3/8" plywood decking then one-piece fiberglass |
| Slideouts |
Electric-powered slideout rooms |
Electric-powered slideout rooms |
Entegra-exclusive Relia-Torque flush-mounted 12V slideout system with VegaTouch and rocker switch controls |
Entegra-exclusive Relia-Torque flush-mounted 12V slideout system with VegaTouch and rocker switch controls |
Entegra-exclusive Relia-Torque flush-mounted 12V slideout system with VegaTouch and rocker switch controls |
| Underbelly |
|
|
|
|
|
| Walls |
Vacuum-bonded, high-gloss gelcoat with R-8 bead-foam insulation |
Vacuum-bonded, high-gloss gelcoat with R-8 bead-foam insulation |
2-1/2" exterior walls with Aluma-Tru™ welded tubular aluminum studs on 16" centers or less filled with bat and Flexfoil insulation then covered with high-gloss gelcoat |
2-1/2" exterior walls with Aluma-Tru™ welded tubular aluminum studs on 16" centers or less filled with bat and Flexfoil insulation then covered with high-gloss gelcoat |
2-1/2" exterior walls with Aluma-Tru™ welded tubular aluminum studs on 16" centers or less filled with bat and Flexfoil insulation then covered with high-gloss gelcoat |
| Air Conditioning |
(3) 15,000-BTU A/C units with heat pumps [(2) 15,000-BTU units with heat pumps on 37K] |
(3) 15,000-BTU A/C units with heat pumps [(2) 15,000-BTU units with heat pumps on 37K] |
(3) 15,000-BTU A/C units with heat pumps and condensation drain system |
(3) 15,000-BTU A/C units with heat pumps and condensation drain system |
(3) 15,000-BTU A/C units with heat pumps and condensation drain system |
| Batteries |
(2) L16 AGM batteries (6V/390 amp hrs. ea.) |
(2) L16 AGM batteries (6V/390 amp hrs. ea.) |
(2) L16 AGM batteries (6V/390 amp hrs. ea.) |
(4) L16 AGM batteries (6V/390 amp hrs. ea.) |
(4) L16 AGM batteries (6V/390 amp hrs. ea.) |
| Black Holding Tank Sprayer |
Black holding tank sprayer |
Black holding tank sprayer |
Black holding tank sprayer |
Black holding tank sprayer |
Black holding tank sprayer |
| Black Tank Management |
Sani-Con® Macerator holding tank dump system with manual gate valves, manual backup and metal door |
Sani-Con® Macerator holding tank dump system with manual gate valves, manual backup and metal door |
Sani-Con® Macerator holding tank dump system with manual gate valves, manual backup and metal door |
Sani-Con® Macerator holding tank dump system with manual gate valves, manual backup and metal door |
Sani-Con® Macerator holding tank dump system with power gate valves, manual backup and metal door |
| Electrical Hookup |
50-amp power cord |
50-amp power cord on electric powered reel |
50-amp power cord on electric powered reel |
50-amp power cord on electric powered reel |
50-amp power cord on electric powered reel |
| Generator |
Onan® 8,000-watt diesel generator, with automatic start, on slide-out tray |
Onan® 10,000-watt diesel generator, with automatic start, on slide-out tray |
Onan® 10,000-watt diesel generator, with automatic start, on slide-out tray |
Onan® 12,500-watt diesel generator, with automatic start, on powered slide-out tray |
Onan® 12,500-watt diesel generator, with automatic start, on powered slide-out tray |
| Gravity Fill |
|
|
|
|
|
| Heating System |
35,000-BTU furnace (37K) / (1) 20,000 and (1) 30,000 (39BH, 39T2) |
Aqua-Hot® 250D hydronic water and heating system |
Aqua-Hot® 400D hydronic water and heating system with in-floor heat throughout |
Aqua-Hot® 450D hydronic water and heating system with in-floor heat throughout and engine preheat |
Aqua-Hot® 450D hydronic water and heating system with in-floor heat throughout and engine preheat |
| Heated Floors |
|
Electric radiant floor heating system |
|
|
|
| Heated Tanks |
Heated basement storage |
Heated basement storage |
Aqua-Hot® heated basement storage |
Aqua-Hot® heated basement storage |
Aqua-Hot® heated basement storage |
| Inverter |
2,000-watt pure sine wave inverter with 100-amp battery charger |
2,000-watt pure sine wave inverter with 100-amp battery charger |
3,000-watt pure sine wave inverter |
3,000-watt pure sine wave inverter |
3,000-watt pure sine wave inverter |
| Power Management |
Automatic transfer switch with surge protection |
Automatic transfer switch with surge protection |
Smart automatic transfer switch with surge protection |
Smart automatic transfer switch with surge protection |
Smart automatic transfer switch with surge protection |
| Propane |
24.5-gal. propane tank |
|
|
|
|
| Transfer Switch |
|
|
|
|
|
| Tank Vents |
|
|
|
|
|
| Water Hose w/ Electric Reel |
|
|
Water hose with electric reel |
Water hose with electric reel |
Water hose with electric reel |
| Water Filtration |
City and tank water filtration system |
City and tank water filtration system |
City and tank water filtration system |
City and tank water filtration system |
City and tank water filtration system |
| Water Heater |
Tankless gas water heater |
|
|
|
|
| Water Monitoring |
|
|
Trutank™ ultrasonic tank monitoring system displayed on VegaTouch screen |
Trutank™ ultrasonic tank monitoring system displayed on VegaTouch screen |
Trutank™ ultrasonic tank monitoring system displayed on VegaTouch screen |
| Water Pump |
|
|
|
|
|
| Winterization Drain System |
Winterizing drain system |
Winterizing drain system |
Winterizing drain system |
Winterizing drain system |
Winterizing drain system |
| Accent Lights |
|
|
LED accent lights under passenger slideout rooms |
LED accent lights under passenger slideout rooms |
LED accent lights under passenger slideout rooms |
| Bike rack |
|
|
|
|
